Product Description
Retro - reflective Thermoplastic Road Marking Material Conforming to MORT &H, 803.4.
Features and Recommended use
- Retro - reflective thermoplastic road marking material with excellent whiteness
- Conforms to clause 803.4 of “Specification for Road & Bridge Works” issued by the Ministry of Road Transport & Highways (MORT &H).
- Designed for tropical Indian conditions
- Based on aliphatic chemistry, offers superior weathering resistance and colour stability
- Intermix glass beads offer long lasting retro - reflectivity
- Optimal balance between melt flow and flow resistance to achieve well defined lines as per the desired width and thickness
- Excellent wear resistance and adhesion on asphalt roads
- Suitable for application with manual, screed/ extrusion automatic machines
Technical Data
| Colour | White & Golden Yellow |
|---|---|
| Composition | White & Golden Yellow |
| Binder | Min 18% |
| Glass beads (Intermix) | Min 30% |
| Tio2 (for White) M | Min 10% |
| Fillers (for White) M ax. 42 | Max 42% |
| Softening Point | 102.5 ± 9.5 ° C |
| Glass Bead (Intermix) | Type I MORT &H/ BS 6088A |
| Yellowness Index (For White) N | Not more than 0.12 |
| Drying time M | Max 15 minutes |
| SDaylight Luminance @ 45° | |
| White | Min. 70% |
| Yellow | Min. 50% |
| Flow resistance | Not more than 25% |
Directions For Use
- Heat the material to 180 - 200°C in the pre - heater with adequate agitation till the material becomes a homogenized liquid.
- E nsure that the road surface is clean, free from dust and moisture.
- Heavy deposits of paint require removal.
- For aged asphalt roads and concrete roads application of Apcogrip, a primer coat is recommended for proper bonding of the material with the road surface.
- E nsure that the primer is thoroughly dry and void of solvent prior to application of the thermoplastic material.
- E nsure temperature of 180 – 200°C and adequate agitation during application.
- D o not hold thermoplastic above 180°C for more than 6 hours.
- D o not heat the material above 220°C at any point of time.
- C hange in colour indicates that the material has been scorched owing to overheating and needs to be discarded.
- D rop - on glass beads must be immediately deposited after thermoplastic application
Storage & Packing:
- Storage: A minimum shelf life of 12 months when stored in a cool, dry and covered place
- Packing:: 25 kg.
- Minimise dusting of the material during use.
- Use of personal protective equipment’s like facemask, goggle, heat resistant gloves, safety shoes and protective clothing while handling the material is recommended.
- Avoid eye contact, if contacted, wash copiously with water.
- Contact of molten product with skin would lead to thermal burns, flush with cold water, do not remove material as it would lead to severe tissue damage.
- E nsure that the primer is thoroughly dry and void of solvent prior to application of the thermoplastic material.
- Please refer our Material Safety Data Sheet prior to using the product.
